Flange Wrap Repair Clamp
BS-RCFLUsually replies within 24 hours sales@baoshuopipe.com
Product Overview
Flange face weeping? Wrap the whole flange — bolts, gasket, all of it — in one shell and seal it from outside. Repairs leaking flanges, flanged tees and weld-neck joints without breaking the joint apart.
Technical Specifications
| Part Number | BS-RCFL |
|---|---|
| Size Range | DN15–DN4000 · Plastic φ90–φ800 / Ductile Iron DN100–DN710 / Steel DN100–DN710 · Custom sizes available beyond the above range |
| Body Material | Q235 Carbon Steel / SS304 / SS316L / Duplex 2205 |
| Seal Material | EPDM |
| Sealing Pressure | ≥1.6MPa (232 PSI) |
| Bolt Specification | M16×80, Grade 8.8 High-Strength Bolts |
| Coating | Epoxy Powder |
| Length Range | 200–800mm (7.9"–31.5") |
| Weight | 2.0–48.0 kg (approx) |
| Applicable Pipe Types | UPVC, HDPE, Steel, Ductile Iron, Cast Iron |
| Working Conditions | Standard Pressure |
Custom Orders Available
This product can be customized to your specifications. Contact us with your requirements.
