Reducing Repair Clamp
Reducing Repair Clamp
BS-RCRD
Size Range
DN20–DN800
Sealing Pressure
≥1.6MPa (232 PSI)
Body Material
Q235 Carbon Steel / SS304 / SS316L / Duplex 2205
Coating
Epoxy Powder
Usually replies within 24 hours sales@baoshuopipe.com
Product Overview
For the awkward spot where pipe diameter changes: the stepped shell follows both sizes and seals the reducer joint that flat clamps cannot bridge. No need to cut out the transition — clamp over it.
Technical Specifications
| Part Number | BS-RCRD |
|---|---|
| Size Range | DN15–DN4000 · Ductile Iron DN20–DN800 / Steel DN20–DN800 · Custom sizes available beyond the above range |
| Body Material | Q235 Carbon Steel / SS304 / SS316L / Duplex 2205 |
| Seal Material | EPDM |
| Sealing Pressure | ≥1.6MPa (232 PSI) |
| Bolt Specification | M16×80, Grade 8.8 High-Strength Bolts |
| Coating | Epoxy Powder |
| Length Range | 150–600mm (5.9"–23.6") |
| Applicable Pipe Types | Steel, Ductile Iron, Cast Iron |
| Working Conditions | Standard Pressure |
Custom Orders Available
This product can be customized to your specifications. Contact us with your requirements.
