Socket Joint Repair Clamp
BS-RCSKUsually replies within 24 hours sales@baoshuopipe.com
Product Overview
Bell-and-spigot leaks are a different geometry: the shell steps over the bell shoulder and seals on both diameters, so the socket is sealed without digging up and re-caulking the joint.
Technical Specifications
| Part Number | BS-RCSK |
|---|---|
| Size Range | DN15–DN4000 · Plastic φ20–φ800 / Ductile Iron DN40–DN2000 / Steel DN40–DN2000 · Custom sizes available beyond the above range |
| Body Material | Q235 Carbon Steel / SS304 / SS316L / Duplex 2205 |
| Seal Material | EPDM |
| Sealing Pressure | ≥1.6MPa (232 PSI) |
| Bolt Specification | M20×100, Grade 8.8 High-Strength Bolts |
| Coating | Epoxy Powder |
| Length Range | 200–500mm (7.9"–19.7") |
| Weight | 0.3–24.4 kg (approx) |
| Applicable Pipe Types | Steel, Ductile Iron, Cast Iron |
| Working Conditions | Standard Pressure |
Custom Orders Available
This product can be customized to your specifications. Contact us with your requirements.
